CP Plus CPUNR4K564R8FI 64Ch AI Network Video Recorder
- Brand: CP Plus
- Product:CP-UNR-4K564R8-FI 64Ch AI Network Video Recorder
- Processor: Industrial-grade processor
- IP Camera Input: 64 Channel
- Operating System: Embedded LINUX
- User Interface: Web, Local GUI
- Face Recognition Performance of AI by Camera (Number of Channels): 16 channels
- SMD Plus by NVR 8 Channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera: All Channels (32 targets/s)
- Metadata Performance of AI by Camera (Number of Channels): 8 channels
- Human Attributes: Top color, Top type, Bottom color, Bottom type, Hat, Bag, Age, Gender and Umbrella
- Motor Vehicle Attributes: License plate, Plate color, Vehicle body, Vehicle model, Vehicle logo, Calling, Seatbelt, Vehicle Interior, Vehicle registration location
- Non-motor Vehicle Attributes: Vehicle model, Vehicle color, Number of persons, Helmet
- ANPR by Camera (Number of Channels): All Channels (8 Targets/s)
- License Plate Database Capacity: 1. Create up to 20,000 plate numbers. 2. Blocklist and allowlist
- Abnormality Alarm: Camera offline, storage error, disk full, IP conflict, MAC conflict, login lock, abnormal behaviour of fan, cyber security exception
- Intelligent Alarm: Face detection, Perimeter protection, Face recognition, Video metadata (Human, Motor vehicles, non-motor vehicles), SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map
- General Alarm: Motion detection, local alarm, alarm box, camera external alarm, network alarm, scene changing, PIR alarm, thermal
- Alarm Linkage: Record, snapshot (panoramic), local alarm output, IPC external alarm output, access controller, audio, buzzer, log, preset, email
- Audio Input: 1-channel RCA
- Audio Output: 2-channel RCA
- Audio Compression: G.711a, G.711u, PCM, G726, AAC
- Disk Group: Support
- Alarm Input: 16 Channel
- Alarm Output: 8 Channels (1-channel 12 V 1 A output)
- Hard Disk: 8 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature
- Multi-channel Playback: Up to 16 channels
- Record Mode: General, Motion detection, Intelligent, Alarm, POS
- Backup Method: USB device and network
- Playback Mode: Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection)
- Smart Phone: iPhone, iPad, Android Phone
- RAID: RAID 0/1/5/6/10
- Interface Ports: 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports), 1 eSATA Port, 1 RS232, 2 RS485 (1 port for halfduplex serial communication, 1 port for full-duplex serial communicat
- Protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, Multicast, InstaOn, Auto Registration, iSCSI, ONVIF 22.06 (Profile T, Profile S, Profile G), CGI, SDK
- Network Mode: Multi-address mode, load balance, fault tolerance and other network port binding modes
- Ethernet: 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Browser: Chrome, IE, Safari, Edge, Firefox
- Power Supply: 100–240 VAC, 50-60 Hz
- Power Consumption: Total output of NVR is ? 13 W (without HDD)
- Operating Temperature: -10 °C to +55 °C
- Operating Humidity: 10%–93% (RH), non-condensing
- Storage Temperature: -20 °C to +60 °C
- Dimensions(W × L × H):439.9 mm × 457.9 mm x 89.0 mm
- Weight: 6.40 kg
