Asustor Lockerstor 10 Gen3 AS6810T Network Attached Storage
- Brand: Asustor
- Part No: AS6810T
- Model No: Asustor Lockerstor 10 Gen3 AS6810T NAS Storage
- CPU Model: AMD Ryzen V3C14
- CPU Architecture: x64 64-bit
- CPU Frequency: Quad-Core 2.3GHz (burst up 3.8 GHz)
- Memory: 16GB ECC DDR5-4800 SO-DIMM
- Memory Module Pre-installed: 16GB (1x 16GB)
- Total Memory Slots: 2
- Memory Expandable up to: 64GB Support mixed capacity, Supports ECC memory, ECC functionality will be disabled if non-ECC memory is installed or mixed with ECC memory
- Flash Memory: 8GB eMMC
- Drive Bays: 10
- M.2 Drive Slots: 4
- Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe
- M.2 PCIe Interface: PCIe 4.0 x1
- Maximum Drive Bays with Expansion Unit: 22
- Supports Hot Swappable Drives: Yes
- Expansion: 3 x USB 3.2 Gen 2 ( 10Gbps ) Type-A, 2x USB4 ports (20Gbps per channel, 40Gbps per port), Host-to-Host connectivity is not supported, Backwards compatible with USB 3.2 Gen 1 and USB 3.2 Gen 1
- Network: 2x 5 Gigabit Ethernet (5G/2.5G/1G/100M), 2x 10 Gigabit Ethernet (10G/2.5G/1G/100M)
- PCIe Expansion Slots: 1x for optional expansion 10 GbE card (Removal of m.2 card necessary for expansion card installation)
- Multimedia Output: N/A
- System Fan: 2x 120mm
- LCD Panel: Yes
- Power Supply Unit/Adapter: 250W x1
- Input Power Voltage: 100V to 240V AC
- Power Consumption: 68 W (Operation); 2.4 W (Sleep Mode)
- Noise Level: 22dB (HDD idle)
- Operation Temperature: 0°C~40°C (32°F~104°F)
- Storage Temperature: -20°C~70°C (-4°F~158°F)
- Humidity: 5% to 95% RH
- Dimensions (HxWxD): 215.5(H) x 293(W) x 230(D) mm
- Weight: 6.55 kg
- Warranty: 3 Years Warranty
