Dell PowerEdge R7425 Rack Server
Processor :
Up to two AMD EPYC Processors with up to 32 cores
Operating System
Canonical Ubuntu Server LTS
Citrix Hypervisor
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Bezel :
Optional LCD bezel or security bezel
Chassis
Depth: 67.73 cm(26.67 in)
Width: 43.4 cm(17.09 in)
Height: 8.68 cm(3.42 in)
Drive Bays
Front Drive Bays: Up to 24 x 2.5” SATA/SAS/NVMe or up to 12x 3.5” SAS/SATA HDD
Mid Drive Bays: Up to 4 x 2.5” NVMe or up to 4x 3.5” SAS/SATA HDD
Rear Drive Bay: Up to 4 x 2.5” or 2 x 3.5” SAS/SATA HDD
Memory
DIMM Speed : Up to 2666MT/s
Memory Type : RDIMM / LRDIMM
Memory Module Slots : 32DDR4 DIMM slots
Maximum RAM : RDIMM 1TB /LRDIMM 2TB
Power Supplies
495W Platinum
750W Platinum
750W Titanium
1100W Platinum
1600W Platinum
2000W Platinum
Storage Controllers
Internal Controllers : PERC H330, H730p, H740p, HBA330
External Controllers (RAID) : H840, 12Gbps PERC9, 10 series PERC x8 slot
Internal Boot : Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SATA SSDs
Storage
Front Bays
Up to 24 x 2.5" SATA/SAS/NVMe
Up to 12 x 3.5" SAS/SATA HDD
Mid Bay
Up to 4 x 2.5" NVMe
Up to 4 x 3.5" SAS/SATA HDD
Rear Bays
Up to 4 x 2.5"
Up to 2 x 3.5" SAS/SATA HDD
Slots
PCIe : 8 x Gen3 slots; 6 x16
Video Card :
1 x VGA
Form Factor :
2U Rack Server
Dimensions & Weight :
Height : 868.0mm (3.4")
Width : 434.0mm (17.1")
Depth : 6773.0mm (26.7")
Weight : 33.4kg (73.6 lbs.)
*Dimensions do not include bezel
Rack Support :
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
Ports
Network Options
4 x 1GE
2 x 10GE + 2 x 1GE
4 x 10GE
2 x 25GE
Front Ports
1 x Dedicated iDRAC direct micro-USB
2 x USB 2.0
1 x VGA
Rear Ports
1 x Dedicated iDRAC network port
1 x Serial
2 x USB 3.0
1 x VGA
