Dell PowerEdge R7515 Rack Server
Processor :
One 2nd Gen AMD EPYC Processor with up to 64 cores
Operating System
Canonical Ubuntu Server LTS
Citrix Hypervisor
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi
Dimensions & Weight
Height : 86.8mm (3.42)
Width : 434.0mm (17.09)
Depth : 647.1mm (25.48)
Weight : 27.3 kg (60.19lb)
Power Supplies :
1600W Platinum
Slots
PCIe : Up to 4: 2 x Gen3 slots (1 x8; 1 x16) ; 2 x Gen4 slots (2 x16)
Rack Support :
ReadyRails sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
ReadyRails sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
Memory
DIMM Speed : Up to 3200MT/s
Memory Type : RDIMM / LDIMM
Memory Module Slots : 16 DDR4 RDIMM/LRDIMM slots
Maximum RAM : RDIMM 1TB / LRDIMM 2TB
Bezel :
Optional LCD bezel or security bezel
Storage
Front Bays
Up to 8 x 3.5” hot plug SATA/SAS (HDD)
Up to 12 x 3.5” hot plug SAS/SATA (HDD)
Up to 24 x 2.5” hot plug SATA/SAS/NVMe
Rear Bays
Up to 2 x 3.5” hot plug SAS/SATA (HDD)
Ports
Network Options
2 x 1GbE
2 x 10GbE BT
2 x 10GbE SFP+
2 x 25GbE SFP28
Front Ports
1 x Dedicated iDRAC direct micro-USB
2 x USB 2.0
1 x Video
Rear Ports
2 x 1GbE
1 x Dedicated iDRAC network port
1 x Serial
2 x USB 3.0
1 x Video
Storage Controllers
Internal Controllers : PERC HBA330, H330, H730P, H740P
External Controllers (RAID) : H840, 12Gbps SAS HBA
Internal Boot
Boot Optimized Storage Subsystem (BOSS): HWRAID 2 x M.2 SATA SSDs
Form Factor :
2U Rack Server
