Dell PowerEdge R540 2U Rack server
- Model : PowerEdge R540
- CPU : Intel Xeon Gold 5218R 2.1GHz, 20Core/40T, 10.4GT/s, 27.5M Cache, Turbo, HT (125Watts) Processor
- Max Memory : 16 DIMMS
- Memory : 1 x 32GB RDIMM
- Max HDD Scalability : Up to 12, 3.5in Hot Plug Hard Drives and 2 x 3.5in Rear Drives
- HARD DISK : 2 X 4TB 7.2K RPM SATA 6Gbps 512n 3.5in Hot-plug Hard Drive
- RAID InBuilt : PERC H330 RAID Controller, Adapter, Low Profile
- POWER SUPPLY : Dual, Hot-plug, Redundant Power Supply, 750Watts
- System Management : iDRAC9,Enterprise
- WARRANTY : 3Years ProSupport 4Hours and Mission Critical
Processor
Intel Xeon Bronze 3204 1.9G, 6C/6T, 9.6GT/s, 8.25M Cache, No Turbo, No HT (85W) DDR4-2133
Memory
8GB RDIMM, 3200MT/s, Single Rank
RAID
C20, No RAID with Embedded SATA for SATA HDDs or SATA SSDs
Hard drive
1TB 7.2K RPM SATA 6Gbps 512n 3.5in Hot-plug Hard Drive
Chassis
Basic Next Business Day 36 Months, 36 Month(s)
Storage
Up to 12 x 3.5” SAS/SATA HDD max 168TB
Power supply
495W Platinum
BAYS
Up to 2 x 3.5” SAS/SATA HDD max 28TB
Slot
1 x full height/full length
chassis
3.5" Chassis with up to 8 Hard Drives and Software RAID
Software RAID
S140
Manangement
iDRAC9 iDRAC RESTful API with Redfish
warranty
3 years Next business day response
