TerraMaster D5 Hybrid 5 Bay Storage
- Brand: TerraMaster
- Model No: TerraMaster D5 Hybrid DAS Storage
- Disk Slot Number: 2
- Compatible Disk Types: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
- File System: NTFS, APFS, Mac OS,FAT32,EXT4,exFAT
- Maximum Internal Raw Capacity: 68 TB (22 TB drive x 2 + 8 TB drive x 3) (Capacity will vary along with the RAID type)
- RAIDs Supported: SINGLE DISK,JBOD,RAID 0,RAID 1
- Hardware RAID: Yes
- USB: USB3.2 Type-C gen2 10Gbps
- Power Socket: DC IN 12V
- Reading Speed (max.): Read?565MB/s ( HDD*2_RAID0 ); Read?960MB/s ( SSD*2_RAID0 )
- Writing Speed (max.): Write?524MB/s ( HDD*2_RAID0); Write?956MB/s ( SSD*2_RAID0 )
- System fan: 80 mm x 80 mm x25mm (x 1)
- Fan mode: Smart
- Noise Level: 19.0 dB(A)
- Power Supply: 40 W
- AC Input Voltage: 100V to 240V AC
- Current Frequency: 50/60 HZ, Single Phase
- Power Consumption: 30 W(Fully loaded Seagate 22TB ST22000NM001E hard drive(s) and SAMSUNG 980 NVMe M.2 SSD in read/write state ), 8.1 W (Fully loaded Seagate 22TB ST22000NM001E hard drive(s) and SAMSUNG 980 NVMe M.2 SSD in hibernation)
- Working Temperature: 0°C ~ 40°C (32°F ~ 104°F)
- Storage Temperature: -20°C ~ 60°C (-5°F ~ 140°F)
- Relative Humidity: 5% ~ 95% RH
- Supported OS: Windows OS?Mac OS?Linux
- Size: 222 x 119 x 154 mm
- Weight: 1.3 Kg
- Warranty: 2 years Warranty
