Dell EMC PowerEdge R650 Rack Server
- Processor :
- Up to two 3rd Generation Intel Xeon Scalable processors with up to 40 cores per processor
- Direct Contact Liquid Cooling (DCLC) option: Yes
- Operating System :
- Canonical Ubuntu Server LTS
- Citrix Hypervisor
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware ESXi
- Chipset : Intel C620 series chipset
- Accelerators : Up to three 75 W single-width GPU
- Memory :
- DIMM Speed
- Up to 3200 MT/s
- Memory Type :
- RDIMM
- LRDIMM
- Intel Persistent Memory 200 series (BPS)
- Memory Module Slots :
- 32 DDR4 DIMM slots
- Maximum RAM :
- RDIMM 2 TB
- LRDIMM 4 TB
- Intel Persistent Memory 200 series (BPS) 8 TB
- Storage :
- Front Bays:
- Up to 10 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 153 TB
- Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 122.8 TB
- Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB
- Rear bays :
- Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.7 TB
- Storage Controllers :
- Internal Controllers
- PERC H745, H345, HBA355I, H755, H755N
- External Controllers : PERC H840, HBA355E
- Software RAID : S150
- Internal Boot : Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
- Mobility :
- OpenManage Mobile
- Power Supplies:
- 800 W Platinum AC/240 HVDC
- 1100 W Titanium AC/240 HVDC
- 1400 W Platinum AC/240 HVDC
- Hot plug power supplies with full redundancy option
- Ports:
- Network Options:
- 2 x 1 GbE LOM and 1 x OCP 3.0 (x8 PCIe lanes) (optional)
- Front Ports:
- 1 x Dedicated iDRAC Direct micro-USB
- 1 x USB 2.0
- 1 x VGA
- Rear Ports:
- 1 x USB 2.0
- 1 x Serial (optional)
- 1 x USB 3.0
- 2 x RJ-45
- 1 x VGA port (optional for liquid cooling configuration)
- Internal Ports:
- 1 x USB 3.0
- Slots:
- Up to 3 x PCIe Gen4 low profile slots (all x16 except one x8 slot with SNAPI I/O option) or 2 x PCIe (Gen4) full height slots
- Video Card:
- 1 x VGA
- Bezel:
- Optional LCD bezel or security bezel
- Form Factor:
- 1U rack server
- Dimensions & Weight:
- Height : 42.8 mm (1.68 inches)
- Width : 482 mm (18.97 inches)
- Depth : 809 mm (31.85 inches) – without bezel
- 822.84 mm (32.39 inches) – with bezel
- Weight : 21.2 kg (46.7 lbs)
