Dell EMC PowerMax 2000 Storage
- Brand : Dell
- Model No : Dell PowerMax 2000
- CPU : Intel Xeon E5-2650-v, 2.5 GHz 12 core
- Number of Bricks : 1 to 2
- Engine Enclosure : 4U
- Capacity Per Array : 13 TBu-1.2 PBe
- Response Time : Under 100 microseconds
- Data Reduction Guarantee : 3.5:1 data reduction (Open)
- Nodes Per Array : 2-4 controllers
- Dynamic virtual matrix interconnect : Direct Connect InfiniBand, 56 Gbps per port
- Max Number of Devices/Secure Snapshots : 64K LUNs / 65M snapshots
- Cache-system min (raw) : 512 GB
- Cache-system max (raw) : 4 TB (with 2,048 GB engine)
- Cache-per engine options : 512 GB, 1 TB, and 2 TB
- Vault stratery : Vault to Flash
- Vault implementation : 2 to 4 NVMe Flash SLICs / Engine
- Maximum front-end I/O modules/brick : 8
- Front-end I/O modules and protocols supports : 4 x 32 Gbs (FC,SRDF), 4 x 32 Gbs (FC-NVMe), 4 x 16 Gbs (FC, SRDF), 10 GbE: 4 x 10 GbE (iSCSI, SRDF), 25 GbE: 4 x 25 GbE (iSCSI, SRDF)
- NVMe Drives Supported : 1.92 TB, 3.84 TB, 7.68 TB, 15.36 TB
- SCM Drives Supported : 750 GB, 1.5 TB
- Dimensions (WxDxH) : 61 cm x 106.7 cm x 190 cm
- Weight System bay, dual engine/ dual system : 431 kg/ 730 kg
