Dell EMC Unity XT 680F Storage
- Brand : Dell
- Model No : Dell Unity XT 680F
- Processors : 2 x dual-socket Intel CPUs, 48 cores, 2.1GHz
- Drive Enclosure : 2.5 (2U), 25 drives and 2.5 (3U), 80 drives
- Memory : 384 GB
- Capacity : 8 PB
- Min/Max Drives : 6/1000
- CAN/Mezz Ports : 25GbE Opt, 10GbE BaseT
- IO Modules : 10GbE BaseT, 16Gb FC, 25GbE Opt, 10GbE Opt, SAS BE
- RAID Options : 1/0, 5, 6
- Voltage : 100 to 240 VAC 10%, single phase, 47 to 63 Hz
- Power Consumption : 1172 VA (1161 W) max at 100 VAC; 1172 VA (1161 W) max at 200 VAC
- AC Protection : 20 A fuse on each power supply, single line
- Heat Dissipation : 4.18 x 106 J/hr, (3,960 Btu/hr) max at 100 VAC; 4.18 x 106 J/hr, (3,960 Btu/hr) max 200VAC
- Dimensions (WxDxH) : 44.72 cm x 79.55 cm x 8.72 cm
- Weight : 25.90 kg
