Graphtec CE7000 130AP Garment Pattern Cutting Plotter
- Brand: Graphtec
- Model No: Graphtec CE7000 130AP Cutting Plotter
- Configuration: Grit rolling type
- Drive method: Digital servo drive
- Max. cutting area (W x L) (*1): 1220 mm × 50 m
- Cutting area of guaranteed accuracy (*1): 1200 mm × 3 m
- Mountable media width (*2): Min. 594 mm, Max. 1321 mm
- Mountable roll media inside-diameter: 3 inches
- Mountable roll media outside-diameter: Max. 200 mm
- Mountable roll media mass: Max. 20 kg
- Number of push rollers: 5 rollers
- Cutting speed: Max. 600 mm/s at all direction
- Cutting force: Max. 4.41N (450gf )
- Mechanical resolution: 0.005 mm
- Programmable resolution: GP-GL?0.1 / 0.05 / 0.025 / 0.01 mm, HP-GLTM (*3)?0.025mm
- Repeatability: Max. 0.1 mm in plot up to 2 m (*1)(*4)
- Mountable number of tools: 2 tool
- Pen types: Oil-based ballpoint pen, Water-based fiber-tip pen
- Interface: USB 2.0 (Full Speed), Ethernet 10BASE-T/100BASE-TX
- Buffer memory: 2MB
- Command sets: GP-GL / HP-GLTM (*3) (Set by command)
- Display: Graphic type LCD with back-light (240dots x 128dots), supports 10 languages
- Power source: 100V to 120V AC, 200V to 240V AC, 50/60 Hz (Auto switch)
- Power consumption: 100W
- Operating environment: 10 to 35 ºC, 35 to 75 % R.H. (non-condensing)
- Guaranteed accuracy environment: 18 to 28 ºC, 40 to 65 % R.H. (non-condensing)
- External dimensions (W x D x H): Approx. 1704 × 1148 × 1215 mm (Including Stand and Basket)
- Weight: Approx. 60kg (Including Stand and Basket)
- Compatible OS (*5): Windows 11
