Juniper QFX5240 64QD PoE Switch
- Brand: Juniper
- Product: QFX5240-64QD Network Switch
- Rack units: 2 U
- System throughput: 51.2/102.4 Tbps uni/bidirectional
- Max Forwarding Rate: 21.2Bpps
- Port density: 64 ports of QSFP-DD 800GbE
- Max ports with breakout: 64 × 800GbE, 128 × 400GbE, 256 x 200GbE, 320 x 100GbE, 256 x 50GbE. Max port density with mixed speeds 320 (please use online port checker to validate mixed speed configurations)
- Operating system: Junos OS Evolved
- Switch chip: Broadcom Tomahawk5
- CPU: Intel Ice Lake (4 core)
- Memory: 32GB (16GBx2) of DDR4
- Storage: 2x480GB
- Power: Redundant (1+1) hot-pluggable 3000W AC (200 to 240V) power supplies
- Cooling Ports-to-PSU (AFO): 4 hot-pluggable fan modules
- Total packet buffer: 165 MB
- Dimensions (W x H x D): 17.26 x 3.46 x 25.52 in (43.8 x 8.8 x 64.8 cm)
- Weight: 22kgs (48.50lbs) fully loaded without optics
- Warranty: 1 year warranty
